Detail Marine Icom M304
Submersible compact body with large LCD and powerful audio Compact and submersible Equivalent to IPX7 ( 1m depth for 30 minutes, except cables) . Large easy-to-see LCD Shows full size channel number with 4-step backlighting. Built-in DSC ( RTCM SC-101) For distress calls, or for position request/ position report.
Details
Frequency range
Tx 156.025– 157.425MHz
Rx 156.050– 163.275MHz
Power supply requirements
13.8V DC ± 15%
Dimensions ( W× H× D)
( Projections not included) 153× 67× 133 mm
61/ 32× 25/ 8× 51/ 4 in
Weight
825g; 1.8lb
Current drain
Transmit ( High) 5.5A
Max. audio output
1.5A
Sensitivity ( at 12dB SINAD; emf) 0.22¼ V typical
Intermodulation rejection 70dB
Audio output power ( 10% dist. / 4© load) 4.5W typical
RF output power 25/ 1W
